Description
The ALEKO LM114 5/8-Inch Regular Hinge J-Bolt for Driveway Gates is a heavy-duty hinge designed for swinging gates and doors. It features a steel female hinge component with a grease fitting and a mounting plate designed to be welded to a steel post. The hinge supports gates weighing up to 265 lbs.
The hinge assembly includes 2 bolts, 2 nuts, and 2 washers, providing the necessary hardware for installation. It is identified by SKU LM114-AP, MPN LM114, and UPC 013964851472.
Key Features
- 5/8-inch regular hinge J-bolt
- Designed for swinging gates and doors
- Steel female hinge construction
- Includes a grease fitting for lubrication
- Includes a plate designed to weld to a steel post
- Supports gates up to 265 lbs.
- Includes 2 bolts, 2 nuts, and 2 washers
- Suitable for driveway gate installations and replacements
Specifications
| Specification | Details |
|---|---|
| Product | Regular Hinge J-Bolt for Driveway Gates |
| Model | LM114 |
| SKU | LM114-AP |
| MPN | LM114 |
| UPC | 013964851472 |
| Product Type | Gate Hardware |
| Component Type | Regular Hinge J-Bolt |
| Hinge Size | 5/8 in. |
| Material | Steel |
| Maximum Weight Capacity | 265 lbs. |
| Application | Swinging Gates & Doors |
| Mounting | Weld-on Plate for Steel Post |
| Grease Fitting | Yes |
| Bolts Included | 2 |
| Nuts Included | 2 |
| Washers Included | 2 |
| Category | Parts for Swing Gate Openers |
